20
2. Installation and Connection
Attaching the power cable stopper
You can prevent the power plug from falling out from the main unit by using the included power cable stopper.
CAUTION:
Do not bundle the power cable. Doing this could cause heat or a fire.
• Do not clamp the power cable with other cables. Doing so can generate noise, which can affect adversely the
signal cable.
• Be careful not to insert the band inversely. Once the band is attached, it cannot be removed from the slot.
Insert the end of band of the power cable stopper into the slot next to the AC IN on the terminal
panel.
Use the power cable stopper to clamp the power cable.
Push the clamper to lock it.
clamper
Slide the clamper to the hilt of the power cable.
This completes the attachment of the power cable stopper.
