ROI-S04488 OPERATION
3-35
Step
Procedure
“N” : signifies not used channel in alarmed or
controlled status for each E1 channel .
“U” : signifies E1 channel which is used.
6. In item No. 10 and item No. 11, 232 (i.e. RS232C) is
standard.
10 Press the “2” key and “Enter” key, then, following item is
displayed,
Note: When AIS RCVD “status” is selected, AIS RCVD is not
indicated under the input signal alarm state. When AIS
RCVD “alarm” is selected, AIS RCVD is indicated
under the input signal alarm state.
11 Press either “0” or “1” key and “Enter” key for setting, if not,
press the “Esc” key,
12 Press the “3” key and “Enter” key, then, following item is
displayed,
Note: When AIS SEND “status” is selected, AIS SEND is not
indicated under the AIS state. When AIS SEND “alarm”
is selected, AIS SEND is indicated under the AIS state.
13 Press either “0” or “1” key and “Enter” key for setting, if not,
press the “Esc” key,
14 Press the “6” key and “Enter” key, then, following item is
displayed,
2. AIS RCVD alarm/status (status)
AIS RCVD alarm/status (status:0 / alarm:1):
3. AIS SEND status/alarm (status)
AIS SEND status/alarm (status:0 / alarm:1):
6. Main channel usage 1-16
(1:used 2:used 3:N/A 4:not used
5:not used 6:not used 7:not used 8:not used
9:not used 10:not used 11:not used 12:not used
13:not used 14:not used 15:not used 16:not used)
Select channel No. :
To Next Page
