OPERATION ROI-S04488
3-36
Step
Procedure
Notes: Set to “on” for the following channels.
1. Restricted E1 channels by hardware, which are
indicated by “#”on the Setting display.
2. E1 channels which are not available to use when 10/
100BASE-T(X) LAN is assigned. (see Table 3-3
Applicable Traffic Channel)
3. Reserved E1 channels.
15 Enter the channel No. and press the “Enter” key to change the
setting, following channel setting is displayed,
16 Press either “0” or “1” key and “Enter” key for setting, if not,
press the “Esc” key,
17 Press the “6” key and “Enter” key, repeat step 14 to step 16 for
each channel setting,
18 If not, press the “7” key and “Enter” key, then, following item is
displayed,
Notes: 10-3 signifies 3
x
10
-3
.
Default value is a 10
-4
.
19 Press the any “0” to “3” key and “Enter” key for setting, if not,
press the “Esc” key,
7. BER alarm threshold (10-4)
BER alarm threshold (10-3:0 ∠ 10-4:1 ∠ 10-5:2
ޓ
∠ 10-6:3):
6. Main channel usage 1-16
(1:used 2:used 3:N/A 4:not used
5:not used 6:not used 7:not used 8:not used
9:not used 10:not used 11:not used 12:not used
13:not used 14:not used 15:not used 16:not used)
Select channel No. :
channel 1 (used:0 / not used:1) :
To Next Page
