ROI-S04488 OPERATION
3-37
Step
Procedure
20 Press the “8” key and “Enter” key, then, following item is
displayed,
21 Press the desired frame ID number and “Enter” key for setting,
if not, press the “Esc” key,
Note: The frame ID number must be set to the same number as
that on the MAIN BOARD at the opposite station as
follows (factory setting status):
•2
x
2MB/4
x
2 MB : 0
•8
x
2MB : 1
• 16
x
2MB : 2
22 Press the “9” key and “Enter” key, then, following item is
displayed,
Note: When the WS INTFC (optional) module is provided in the
16
x
2MB system, WS alarm INH is set to used.
23 Press either “0” or “1” key and the “Enter” key for setting, if
not, press the “Esc” key,
24 Enter 10 and “Enter” key, then, following item is displayed,
25 Press the either “0” or “1” key and “Enter” key for setting, if
not, press the “Esc” key,
Note: 232 — RS-232C provides standard
64k — 64 kbps is applicable when optional 64K INTFC is
provided.
8. Frame ID (0)
Input ID No. (0-7) :
9. WS channel usage (not used)
WS channel usage (used:0 / not used:1):
10. DSC 1 (232)
DSC 1 (232:0 / 64k:1):
To Next Page
