OPERATION ROI-S04488
3-38
Step
Procedure
26 Enter 11 and the “Enter” key, then, following item is displayed,
27 Press any “0” to “3” key and “Enter” key for setting, if not,
press the “Esc” key,
Note: 232 — RS-232C provides standard,
422 — RS-422 is applicable when optional DSC INTFC is
provided,
485 (TERM)— RS-485 (Terminating) is applicable when
optional ASC INTFC is provided,
485 (NON TERM)— RS-485 (Non-Terminating) is
applicable when optional ASC INTFC is provided.
28 Enter 12 and press the “Enter” key, then, following item is
displayed,
29 Press the “0” or “1” key and “Enter” key for setting, if not, press
the “Esc” key,
30 Enter 13 and press the “Enter” key, then, following item is
displayed,
Note: The following display is for initial values. When the
resetting of item is required, perform steps 31 to 35 for
corresponding item.
11. DSC 2 (232)
DSC 2 (232:0 / 422:1 / 485(TERM):2 / 485(NON TERM):3):
12. DEM invert (off)
DEM Invert (off:0 / on:1) :
To Next Page
