xiii
Important Information
Laser light radiation range
The gure below shows the maximum radiation range of the laser light.
(unit: degree)
Horizontal angle H
Lens Zoom
Tele Wide
NP45ZL 22.0 28.3
NP46ZL 17.4 22.1
NP47ZL 13.9 18.2
NP48ZL 7.0 13.8
NP49ZL 4.0 7.0
Vertical angle V
Lens Zoom
Tele Wide
NP45ZL 14.1 18.5
NP46ZL 11.1 14.2
NP47ZL 8.8 11.6
NP48ZL 4.4 8.7
NP49ZL 2.5 4.4
H
H
V
V
