A-6 System Specifications
Sound System
The system board features the Yamaha DS1-L PCI accelerator and Analog
Devices AD1819A SoundPort codec. The chips provide the following features:
32-voice XG wavetable
3D stereo
support for DirectX
full-duplex audio
PC/PCI support for legacy DMAC emulation.
The optional AWE64D PCI sound board replaces the integrated audio system. It
provides FM synthesis and 64 simultaneous voices.
Dimensions
System Unit
Height 17.1 in. (43.43 cm)
Desktop Width 6.5 in. (16.51 cm)
Minitower Width 7.8 in. (19.81)
Depth 17.3 in. (43.94 cm)
Keyboard
Height 1.6 in. (4.1 cm)
Width 19.0 in. (48.3 cm)
Depth 8.4 in. (21.3 cm)
Weight
The following weights are averages. Weights depend upon the system
configuration.
System Unit 27.5 lb (12.46 kg)
Keyboard 3.5 to 4 lb (1.6 to 1.8 kg)
Power
Universal Power Supply 235 W
Power Management Partial- and full-power reductions, Sleep button
