3-26 Option Installation
RS-232C Device Connection
Note:
Before connecting a serial device to the system,
be sure the serial device is set up correctly. Follow the setup
instructions that come with the option.
1. Turn off power to the system and to the serial device.
2. Connect one end of the serial cable to one of the serial ports on the rear of
the computer (see the following figure).
3. Secure the cable with the screws provided.
4. Connect the other end to the serial device.
5. Turn on the serial device and the computer.
Locating the Serial Ports
A
– Serial Port 1
B
– Serial Port 2
