A-2 System Specifications
This section describes system specifications.
Processor
Microprocessor 350-MHz, 400-MHz, or 450-MHz Pentium II processor or
500-MHz Pentium III processor
Clock Rate
350 MHz internally, 100 MHz FSB
400 MHz internally, 100 MHz FSB
450 MHz internally, 100 MHz FSB
500 MHz internally, 100 MHz FSB
Processor Support
32-bit addressing
64-bit data
Primary Cache 32 KB of internal write-back cache on processor
Secondary Cache 512 KB of pipeline burst cache
Processor Mounting
Processor subsystem is inserted into slot 1 on the system board.
A 242-pin edge connector is implemented on the processor board for
system board installation.
Retention Mechanism (RM) is inserted over slot 1 to act as an insertion
guide and prevent movement of processor after subsystem mounting.
For thermal protection, a heatsink is supported by a Heat Sink Support
(HSS) which is attached to the system board.
Random Access Memory
Standard Random Access Memory (RAM) 32 MB to 384 MB of 100-MHz
SDRAM installed in industry-standard DIMM sockets on system board
Total Memory support for up to 384 MB of high-speed PC100 SDRAM
DIMM type gold-plated, dual in-line modules (DIMMs)
Expansion expandable using the following modules:
4-Mbit by 64 (32-MB DIMM)
8-Mbit by 64 (64-MB DIMM)
16-Mbit by 64 (128-MB DIMM)
