P 268 rev. 1.0
07-2006
Programming Menu summary
The vending machines can function in 3 different operating modes:
- Normal vending mode
- Filler menu
- Technician menu
In order to access the programming menus, press the programming button located on the coin mechanism
compartment:
At this point the machine goes into Filler Menu mode.
The buttons shown in the figure are used for surfing through the different menus:
Scrolling buttons UP ( ) and DOWN ( )
The UP and DOWN scrolling buttons are used for moving from one programming menu item to the the next one,
located in the same level, and at the same time change the status or the numeric value of the corresponding
functions.
Confirm / Enter button ( )
The confirm / enter button is used for moving to the lower level or for confirming a value after being entered or
changed.
Exit button ( )
The exit button is used for returning to the higher level or for exiting a change field of a function. When reaching
the highest level in the menu, this button is pressed for going from the Technician menu into the Filler menu and
vice versa.
