FlexPAK 800/1000
35
EN
NOTE! Presep overrides 2 above.
NOTE! If TVFDAdv is acvated (Switch = On), TVFDAdv overrides 1 and 2 above.
5.2.3 Timer sengs
BinOpnTm
TL = Delay aer the upper slide starts to close before the lower slide starts to open. The
default is 5 seconds.
TH = Emptying Time. The default is 5 seconds.
PresepTm
TL = Delay aer lower slide starts to close before the upper slide starts to open. The default
is 5 seconds.
TH = Time delay to the next possible emptying sequence. The default is 5 seconds.
5.3 Pre-Separator Sengs
5.3.1 Hardware
• Pre-Separator 1 controlled by the V11 TVFD (SLV) Solenoid Lower Valve.
• Pre-Separator 2 controlled by the V12 TVFD (SUV) Solenoid Upper Valve.
5.3.2 PLC Sengs
1. Presep (Sokey) = On (standard seng=O)
2. AEB-TVFD (Sokey) =O (standard seng=On)
3. TVFDAdv (Sokey) = O (standard seng)
NOTE! Presep overrides 2 above.
NOTE! If TVFDAdv is acvated (Switch = On), TVFDAdv overrides 1 and 2 above.
5.3.3 Timer sengs: Pre-Separator 1
BinOpnTm
TL = Delay before Pre-Separator 1 starts bin emptying. The default is 5 seconds.
TH = Emptying Time. The default is 5 seconds.
5.3.4 Timer sengs: Pre-Separator 2
PresepTm
TL = Delay aer Pre-Separator 1 starts to close before Pre-Separator 2 starts to open.
TH = Emptying Time. Default 5 second
