MRX920 Overview
2-2 MRX920/MTX950 User’s Manual
Figure 2.1 MRX920 Unit
The Laptop
The laptop computer on the MRX920 unit, as shown in Figure 2.2,
is part of the overall MRX920 data collector. It communicates with
the receiver through a serial link using the software, which
decodes and records the collected readings by the receiver.
Laptop Computer
USB Flash Drive
inserts here
Receiving/
Processing Unit
Do not attempt to open the bottom of the MRX920 carrying case. Attempting to repair
or modify the unit on your own can result in personal injury or damage to the unit and
will void the warranty.
