Setting Up the MRX920 Unit
3-6 MRX920/MTX950 User’s Manual
2 Insert the appropriate end of the vehicle power supply power
cable into the connector on the MRX920 unit, as illustrated in
Figure 3.6.
Figure 3.6 Vehicle Power Supply Power Cable
3 Plug the other end of the power cable into the vehicle power
supply receptacle as illustrated in Figure 3.7.
Figure 3.7 Vehicle Power Supply Power Cable Inserted In Car
Vehicle Power Sup-
ply Cable
Vehicle Power Sup-
ply Receptacle
