USE AND MAINTENANCE MANUAL
NERONE MID
45
EN
10.2.1. DOOR DISASSEMBLY FOR MAINTENANCE OPERATIONS
Pay attention when removing the door of the device. The door is heavy!
The oven door can be disassembled to facilitate some maintenance operations.
After removing the door, place it carefully on a surface.
To disassemble the door, proceed as described:
STEP ACTION
1 Open the door all the way.
2 Unscrew the 2 door holding pins and then remove it using a large flat head screwdriver.
3 Remove the doors from the seats of the hinges.
4 To reassemble the door, perform this procedure in reverse order.
1
2
3
