USE AND MAINTENANCE MANUAL
NERONE MID
49
EN
10.2.5. LAMP REPLACEMENT
Do not start the oven without repositioning the lamp-cover.
Danger of electrical shocks or burns!
Only use lamps with the same technical specifications. Place a cloth on the lower internal part of the oven, to protect the lamp
in case it falls.
Proceed as described to replace the lamp:
STEP ACTION
1 Open the door all the way.
2
Disassemble the tray support on the side of the lamp to be replaced (as indicated in paragraph “TRAY
SUPPORTS DISASSEMBLY”).
3 Remove the glass cover of the lamp, unscrewing the 4 fixing screws with a Philips screwdriver.
4 Unhook the lamp and remove it.
5
Replace the lamp with a new one having the same characteristics.
Note:the lamp must be suitable for high temperatures.
6 To reassemble the lamp, perform this procedure in reverse order.
1
3
4
