NERONE MID
EN
48
10.2.4. TRAY SUPPORTS DISASSEMBLY
To disassemble the tray supports, proceed as follows:
STEP ACTION
1 Open the door all the way.
2 Unscrew the 4 fixing screws of the support.
3 Extract the support from the cooking chamber.
4 Repeat the operation for the opposite support if necessary.
5 To reassemble the support, perform this procedure in reverse order.
1
2
3
