NETGEAR DM111P User Manual

Broadband ADSL2+ Modem User Manual
Configuring Your Internet Connection 1-9
v1.0, October 2014
LAN IP Setup
If you intend to connect your modem to a router, configure the local area network Internet Protocol
(LAN IP) settings, as follows:
1. Select LAN IP Setup from the main menu to display the following screen:
2. Check the LAN IP address of your router, which is usually printed on a label on the bottom or
at the rear of the device.
Note how the address is comprised of four numbers separated by period characters. If
necessary, change the LAN IP address of the modem so that the two left-most numbers of the
address are the same as the two left-most numbers of the router’s LAN IP address, and the
third number in the modem’s address is different from the third number in the router’s address.
For example, if the router’s LAN IP address is the same as the modem’s default address
(192.168.0.1), change the LAN IP address of the modem to 192.168.1.1.
Figure 1-5
Tip: If you change the LAN IP address of the modem, write the new address on a
sticky label and attach it to the bottom of the unit. You will need the new
address to access the modem management utility in the future.

NETGEAR DM111P Specifications

Power

power requirements	12V DC, 1.0A
power adapter localization	Plug is localized to country of sale, RoHS compliant

Operating Environment

operating temperature	0° to 40°C (32 to 104ºF)
non-operating temperature	-20° C to 70° C
operating humidity	10-90% relative humidity, noncondensing
non-operating humidity	5-95% relative humidity, noncondensing

System Memory

flash memory	2 MB
DRAM	8 MB

Weight and Dimensions

height	3.0 cm
width	14.1 cm
depth	9.3 cm
weight	190 g (0.67 lb)
