Reference Manual for the ProSafe Wireless 802.11g Firewall/Print Server Model FWG114P
8-2 Maintenance
December 2003, M-10177-01
The Router Status screen shows the following parameters:
Table 8-1. Status Fields
Field Description
System Name The System Name assigned to the router.
Firmware Version The router firmware version.
Printer Status The printer status.
WAN Port These parameters apply to the Internet (WAN) port of the router.
MAC Address This field displays the MAC address being used by the Internet (WAN)
port of the router.
IP Address This field displays the IP address being used by the Internet (WAN) port
of the router. If no address is shown, the router cannot connect to the
Internet.
DHCP This field if the WAN port DHCP settings are dynamic or static.
IP Subnet Mask This field displays the IP Subnet Mask being used by the Internet (WAN)
port of the router.
Domain Name Server Identifies the IP address of the DNS server(s).
LAN Port
MAC Address The Media Access Control address being used by the LAN port of the
router.
IP Address The IP address being used by the Local (LAN) port of the router. The
default is 192.168.0.1
DHCP Identifies if the router’s built-in DHCP server is active for the LAN
attached devices.
IP Subnet Mask The IP Subnet Mask being used by the Local (LAN) port of the router.
The default is 255.255.255.0
Wireless Port
Name (SSID) This field displays the wireless network name (SSID) being used by the
wireless port of the router. The default is Wireless.
Region This field displays the MAC address being used by the wireless port of
the router.
Channel/Frequency Identifies if the channel the wireless port is using. See “Wireless
Channels” on page D-7 for the frequencies used on each channel.
Mode Identifies if the channel the wireless port is set for 802.11b, 802.11g or
both.
Wireless AP Identifies if the wireless access point is on or off.
