NETGEAR FWG114P User Manual

Reference Manual for the ProSafe Wireless 802.11g Firewall/Print Server Model FWG114P
Maintenance 8-5
December 2003, M-10177-01
WAN Status action buttons are described in Table 8-2
Viewing a List of Attached Devices
The Attached Devices menu contains a table of all IP devices that the router has discovered on the
local network. From the Main Menu of the browser interface, under the Maintenance heading,
select Attached Devices to view the table, shown below.
Figure 8-4: Attached Devices menu
Collisions The number of collisions on this interface since reset or manual clear.
Tx B/s The current transmission (outbound) bandwidth used on the interfaces.
Rx B/s The current reception (inbound) bandwidth used on the interfaces.
Up Time The amount of time since the router was last restarted.
Up Time The time elapsed since this port acquired the link.
Poll Interval Specifies the intervals at which the statistics are updated in this window. Click on Stop
to freeze the display.
Table 8-2. Connection Status action buttons
Field Description
Set Interval Enter a time and click the button to set the polling frequency.
Stop Click the Stop button to freeze the polling information.
Table 8-1. Router Statistics Fields (continued)
Field Description
