NETGEAR FWG114P User Manual

Reference Manual for the ProSafe Wireless 802.11g Firewall/Print Server Model FWG114P
Introduction 2-9
December 2003, M-10177-01
The FWG114P Rear Panel
The rear panel of the FWG114P Wireless Firewall/Print Server contains the port connections listed
below.
Figure 1-2: FWG114P Rear Panel
Viewed from left to right, the rear panel contains the following features:
• Wireless antenna
• DB-9 serial port for modem connection
• USB 2.0 Printer Port
• Factory Default Reset push button
• Four Ethernet LAN ports
• Internet Ethernet WAN port for connecting the router to a broadband modem
• AC power adapter outlet
12VDC, 1.0A
4321
IN TERN ET
LO CA L
10/100M
USB
MODEM
