Reference Manual for the ProSafe Wireless 802.11g Firewall/Print Server Model FWG114P
Connecting the FWG114P to the Internet 3-5
December 2003, M-10177-01
c.
Connect the Ethernet cable from the broadband modem to the FWG114P Internet port (A).
Figure 3-2: Connect the broadband modem to the router
d.
Connect the Ethernet cable that came with the router from a Local port on the router (B) to
your computer.
Figure 3-3: Connect the computers on your network to the router
Note: The FWG114P incorporates Auto Uplink
TM
technology. Each LOCAL Ethernet port
will automatically sense if the cable should have a normal connection or an uplink
connection. This feature eliminates the need to worry about crossover cables because Auto
Uplink will make the right connection for either type of cable.
e. Now, turn on your computer. If software usually logs you in to your Internet connection,
do not run that software or cancel it if it starts automatically.
FWG114P ProSafe 802.11g
Wireless Firewall/Print Server
12VDC, 1.0A
4321
INTERN ET
LOC AL
10/100M
USB
MODEM
Broadband modem
A
FWG114P ProSafe 802.11g
Wireless Firewall/Print Server
12VDC, 1.0A
4321
INTERN ET
LOC AL
10/100M
USB
MODEM
Broadband modem
B
