Service Statistics
Use the Service Statistics page to display service-level statistical information about all
interfaces that have DiffServ policies attached.
To display the page, click the QoS DiffServ tab and then click the Advanced Service
Statistics link.
The following table describes the information available on the Service Statistics page.
Field Description
Interface Displays the interface for which service statistics are to display.
Direction Displays the direction of packets for which service statistics display, which is always
In.
Policy Name Displays the policy associated with the selected interface.
Operational Status Displays the operational status of this service interface, which is either Up or Down.
Discarded Packets Displays the total number of packets discarded for all class instances in this service
policy for any reason due to DiffServ treatment. This is the overall count per-interface,
per-direction.
Member Classes Selects the member class for which octet statistics are to display.
Click Refresh to update the page with the most current information.
