Table 1. LEDs of the full 10G models (Continued)
DesignationLED
Left side speed LED:
Off. No link is established on the port.
Solid green. The port established a 1000 Mbps link.
Solid yellow. The port established a 10 or 100 Mbps link.
OOB Ethernet port LEDs
(two LEDs per port)
Right side activity and link LED:
Off. No link is established on the port.
Solid green. The port established a link.
Blinking green. The port is transmitting or receiving packets.
Off. No SFP module link is established on the fiber port.
Solid green. The fiber port established a 10 Gbps link.
Blinking green. The fiber port is transmitting or receiving packets at 10 Gbps.
Solid yellow. The fiber port established a 1 Gbps link.
Blinking yellow. The fiber port is transmitting or receiving packets at 1 Gbps.
10GBASE-X SFP+ port
LED
(one LED per port)
Off. No link is established on the copper port.
Solid green. The copper port established a 10 Gbps link.
Blinking green. The copper port is transmitting or receiving packets at 10 Gbps.
Solid yellow. The copper port established a 1 Gbps or 100 Mbps link.
Blinking yellow. The copper port is transmitting or receiving packets at 1 Gbps or 100
Mbps.
Non-PoE models
10GBASE-T RJ45 port
LED
(one LED per port)
PoE model (M4300-16X), right side PoE status LED:
Off. A PD is not connected to the port.
Solid green. A PoE-powered device (PD) is connected and the port is supplying power
successfully.
Solid yellow. Indicates one of the following failures, which prevents the port from
supplying power:
•
A short circuit occurred on the PoE power circuit.
•
The PoE power demand exceeds the available power.
•
The PoE current exceeds the PD’s classification.
•
An out-of-proper-voltage band condition occurred.
PoE model (M4300-16X)
10GBASE-T RJ45 port
LEDs
(two LEDs per ports)
PoE model (M4300-16X), left side speed, activity, and link LED:
Off. No link is established on the copper port.
Solid green. The copper port established a 10 Gbps link.
Blinking green. The copper port is transmitting or receiving packets at 10 Gbps.
Solid yellow. The copper port established a 5 Gbps, 2.5 Gbps, 1 Gbps, or 100 Mbps
link.
Blinking yellow. The copper port is transmitting or receiving packets at 5 Gbps,
2.5 Gbps, 1 Gbps, or 100 Mbps.
Hardware Installation Guide22Hardware Overview
M4300 Intelligent Edge Series Fully Managed Stackable Switches
