Table 5. Supported PSUs (Continued)
RPS SupportPower RedundancyPossible PSU ConfigurationsSwitch Model
1x APS250W
2x APS250W
M4300-48X
1x APS250W
2x APS250W
M4300-48XF
Note: For models M4300-28G-POE+ and M4300-52G-POE+, the switch automatically
selects the APS1000W PSU to provide the power and turns off the APS550W PSU. If the
APS1000W PSU is removed or fails, the switch uses the APS550W PSU to provide the
power and might reboot if the consumed power is more than the power that the
APS550W PSU can provide.
PoE power budgets
The PoE power budgets for models M430-16X, M4300-28G-POE+, and
M4300-52G-POE+ differ and depend on the installed PSU or PSUs. The following tables
describe the PoE power budgets.
Table 6. PSU and PoE budgets for model M4300-16X
M4300-16X
PoE Power Budget
PSU ConfigurationPSU
(Single PSU only)
199W110 VAC or 220 VAC inputAPS299W
500W110 VAC or 220 VAC inputAPS600W
Table 7. PSUs and PoE budgets models M4300-28G-POE+ and M4300-52G-POE+
M4300-52G-POE+
PoE Power Budget
M4300-28G-POE+
PoE Power Budget
PSU ConfigurationPSU
(Single or dual PSU)
480W480W110 VAC or 220 VAC inputSingle APS550W
480W480W1+1 RPS mode, 110 VAC or 220 VAC inputDual APS550W
720W720WEPS mode, 110 VAC or 220 VAC input
591W630W110 VAC inputSingle APS1000W
860W720W220 VAC input
Hardware Installation Guide45Hardware Overview
M4300 Intelligent Edge Series Fully Managed Stackable Switches
