Configure System Information
71
Smart Managed Pro Switches MS510TX and MS510TXPP
The following table describes the LLDP device information and port summary information.
6. To view additional details about a port, click the port (which is a hyperlink) in the Interface
column of the Port Information table.
The following table describes the detailed local information that displays for the selected
port.
Field Description
Device Information
Chassis ID Subtype The type of information used to identify the switch in the Chassis ID field.
Chassis ID The hardware platform identifier for the switch.
System Name The user-configured system name for the switch.
System Description The switch description, which includes information about the product model
and platform.
System Capabilities The primary functions that the switch supports.
Interface The interface associated with the rest of the data in the row.
LLDP Local Information
Port ID Subtype The type of information used to identify the interface in the Port ID field.
Port ID The port number.
Port Description The user-defined description of the port. For information about how to
configure the port description, see Configure the Port Settings on page 88.
Advertisement The TLV advertisement status of the port.
Field Description
Managed Address
Address SubType The type of address the management interface uses, such as an IPv4
address.
Address The address used to manage the device.
Interface SubType The port subtype.
Interface Number The number that identifies the port.
MAC/PHY Details
Auto Negotiation Supported Indicates whether the interface supports port speed autonegotiation. The
possible values are True and False.
Auto Negotiation Enabled The port speed autonegotiation support status. The possible values are True
(enabled) or False (disabled).
Auto Negotiation Advertised
Capabilities
The port speed autonegotiation capabilities such as 1000BASE-T half-duplex
mode or 100BASE-TX full-duplex mode.
