Nighthawk AX8 8-Stream AX6000 WiFi Router
Hardware Setup 11 User Manual
Ethernet LEDs for ports 1–5 The LED color indicates the speed: white for Gigabit Ethernet connections and amber for 100
Mbps or 10 Mbps Ethernet connections.
Solid white. The router detected a 1 Gbps link with a powered-on device.
Blinking white. The port is sending or receiving traffic at 1 Gbps.
Solidamber. The router detected a 100 Mbps or 10 Mbps link with a powered-on device.
Blinkingamber. The port is sending or receiving traffic at 100 Mbps or 10 Mbps. Off. No
device is connected to this Ethernet port.
Solid white. A USB device is connected and is ready.
Blinking white. A USB device is plugged in and is trying to connect. Off. No USB
device is connected, or someone clicked the Safely Remove Hardware button and
it is now safe to remove the attached USB device.
Solid white. A USB device is connected and is ready.
Blinking white. A USB device is plugged in and is trying to connect. Off. No USB
device is connected, or someone clicked the Safely Remove Hardware button and
it is now safe to remove the attached USB device.
Pressing the WiFi button for two seconds turns WiFi LED and WiFi radios on and off.
If this LED is lit, the WiFi radios are on. If this LED is off, the WiFi radios are turned off
and you cannot use WiFi to connect to the router.
WPS LED Pressing the WPS button lets your WPS-enabled device join your router's WiFi
network without typing the WiFi password. The WPS LED blinks white during the WPS
process and then lights solid white when the WPS-enabled device connects to your
router's WiFi network.
Note: If the LED On/Off switch on the rear panel is moved to the Off position, all the LEDs except
the Power LED are turned off.
Rear Panel
The following figure shows the rear panel connectors and buttons.
