Nighthawk AX8 8-Stream AX6000 WiFi Router
Manage Network Settings 70 User Manual
The user name is admin. The default password is password. The user name and password are
case-sensitive.
The BASIC Home page displays.
3. Select ADVANCED > Advanced Setup > VLAN/Bridge Settings. The VLAN/Bridge Settings page
displays.
4. Select the Enable VLAN/Bridge Setup check box.
The page expands.
5. Select the By VLAN tag group radio button. The page expands.
6. Click the Add button.
The Add VLAN Rule page displays.
7. Specify the settings as described in the following table.
Name Enter a name for the VLAN tag group.
The name can be up to 10 characters.
Enter a value from 1 to 4094.
Enter a value from 0 to 7.
Select the check box for a wired LAN port or WiFi port.
If your device is connected to an Ethernet port on the router, select the LAN port check box that corresponds to the
Ethernet port on the router to which the device is connected. If your device is connected to your router’s WiFi
network, select the WiFi check box that corresponds to the router’s WiFi network to which the device is connected.
You must select at least one LAN port or WiFi port. You can select more than one port.
8. Click the Add button.
The VLAN tag group is added.
9. Click the Apply button.
Your settings are saved.
Set up an IPTV port
You can set up the router to create an Internet Protocol television (IPTV) port that can lease an
IP address from your IPTV service provider. Use this feature only if you subscribe to an IPTV
service and your IPTV service requires an intranet address.
