Manage Your Network
85
VDSL Voice Gateway
• Connection Status. The status of the connection: Connected, Disconnected,
Negotiation (---, Success), or Authentication (---, Success). --- indicates failure.
• Negotiation.
• Authentication.
• IP Address. The IP address that is assigned to the gateway.
• Subnet Mask. The subnet mask that is assigned to the gateway.
Update the Firmware
The gateway firmware (routing software) is stored in flash memory. You might see a
message at the top of the genie screens when new firmware is available. You can respond to
that message to update the firmware, or you can check to see if new firmware is available,
and to update your product.
To manually update your gateway with firmware that you downloaded:
1. Launch a web browser from a computer or wireless device that is connected to the
network.
2. Type http://routerlogin.net or http://10.0.0.2.
A login screen displays.
3. Enter the gateway user name and password.
The user name is admin. The default password is admin. The user name and password
are case-sensitive.
The BASIC Home screen displays.
4. Select ADVANCED > Administration > Router Update.
5. Click Browse, navigate to the firmware file (the file ends in .img), and select the firmware
file.
6. Click the Upload button.
WARNING:
To avoid the risk of corrupting the firmware, do not interrupt the
upgrade. For example, do not close the browser, click a link, or load
a new page. Do not turn off the gateway.
A progress bar shows the progress of the firmware upload process.
When the upload is complete, your gateway restarts. The upload process can take up to
three minutes and the upgrade process typically takes about one minute. To determine
whether you need to reconfigure the gateway after upgrading, read the new firmware
release notes.
