NETGEAR WGT624 v4 User Manual

Super G Wireless Router WGT624 v4 User Manual
5-22 Advanced Configuration
v1.0, July 2008
Expanding Your Wireless Network
The WGT624 v4 wireless router can be used with a wireless access point (AP) to build large
bridged wireless networks. Wireless repeating is a type of Wireless Distribution System (WDS).
The following figure shows a wireless repeating scenario:
In the scenario shown, the following conditions must be met for both APs:
• Both APs must use the same SSID, wireless channel, and encryption mode (see information
about WEP in “WEP Wireless Security” on page 2-6”).
• Both APs must be on the same LAN IP subnet. That is, all the AP LAN IP addresses are in the
same network.
• All LAN devices (wired and wireless computers) must be configured to operate in the same
LAN network address range as the APs.
Warning: If you use the wireless repeating function, your options for wireless security
are limited to None or WEP. For more information about wireless security, see
“Understanding Wireless Security” on page 2-2.”
Figure 5-12
PCs
Repeater
Base Station

NETGEAR WGT624 v4 Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
LAN Ports	4 x 10/100 Mbps
WAN Port	1 x 10/100 Mbps
Security	WEP, WPA, WPA2
Wireless Data Rates	Up to 54 Mbps
VPN Pass-through	Yes
Antenna	2 x external
Interface	Ethernet
Firewall	NAT, SPI
Weight	0.66 lbs
