NETGEAR Wireless-N Access Point WN802T v2 Reference Manual
Introduction 1-3
v1.0, September 2008
System Requirements
Before installing the WN802T v2, make sure your system meets the following requirements:
• A 10/100/1000 Mbps Local Area Network device such as a hub, switch or, router.
• The Category 5 UTP straight through Ethernet cable with RJ-45 connector included in the
package, or one like it.
• A 100-240 V, 50-60 Hz AC Switching Power Supply.
• A Web browser for configuration such as Microsoft Internet Explorer 6.0 or later, or Mozilla
Firefox 1.5 or later.
• Microsoft Windows Vista, XP, 2000, 98, Me, Mac OS, Unix, or Linux and TCP/IP (protocol)
installed.
• 802.11bgn or 802.11bg - compliant devices.
What is in the Box
The product package should contain the following items:
• NETGEAR Wireless-N Access Point WN802T v2.
• 12V, 1A Switching Power Supply.
• Vertical stand.
• Category 5 (CAT5) Ethernet cable.
• Resource CD.
• NETGEAR Wireless-N Access Point WN802T v2 Reference Manual.
• Warranty and Support Information Card.
If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the
carton, including the original packing materials, in case you need to return the Access Point for
repair.
Front Panel of the NETGEAR Wireless-N Access Point
The front panel of the NETGEAR Wireless-N Access Point houses three LEDs that display the
status of power to the wireless access point, Ethernet connectivity and whether a wireless signal is
being sent. To identify the status lights on the front panel of the WN802T v2 and verify connection
refer to Table 1-1.

NETGEAR WN802T Specifications

General

Maximum data transfer rate	300 Mbit/s
MAC address filtering	Yes
Minimum system requirements	-Internet Explorer 6.0; -4 GHz 802.11n / 2.4 GHz 802.11 b/ g;
Compatible operating systems	Microsoft Windows 98, Me, 2000, XP, Mac OS, UNIX, / Linux

Weight and Dimensions

Weight	560 g
Dimensions (WxDxH)	225.5 x 172 x 39 mm
