NETGEAR Wireless-N Access Point WN802T v2 Reference Manual
Management 4-15
v1.0, September 2008
RADIUS Server Settings Fields
Table 4-3. RADIUS server settings fields
Field Description
Primary and Secondary
Authentication Servers
The Authentication RADIUS server provides authentication and access control.
The primary server is mandatory. A secondary server, which will be used if the
primary server fails, is optional.
IP Address The IP address of the authentication server. If no server is present leave blank.
Port Number The port number used for communication to the authentication server. The
default port number for an authentication server is 1812.
Shared Secret The shared secret to establish a client connection to the RADIUS server, as
entered on the server itself.
Re-authentication Time The time interval in seconds after which the supplicant will be authenticated
again with the RADIUS Server.
The default interval is 3600 seconds.
Update Global Key Enable this option to have the Global Key changed according to the time
interval specified. If enabled, enter the desired time interval.
The default is enable, and the default interval is 1800 seconds
Primary and Secondary
Accounting Servers
The Accounting RADIUS Server provides accounting services. The same
RADIUS server may be used for both authentication and accounting, but the
port numbers for authentication and accounting must be different. The
accounting servers are optional.
IP Address The IP address of the accounting server. If no server is present leave blank.
Port Number The port number used for communication to the accounting server. The default
port number for an accounting server is 1813.
Shared Secret The shared secret to establish a client connection to the RADIUS server, as
entered on the server itself.
