NETGEAR WN802T User Manual

NETGEAR Wireless-N Access Point WN802T v2 Reference Manual
4-6 Management
v1.0, September 2008
To reboot the wireless access point from the user interface:
1. From the main menu of the browser interface, select Maintenance > Reset and then Reboot
AP on the side menu. The Reboot AP screen displays as follows:.
2. Select the Yes radio button next to the Reboot option, and then click Apply.
To erase the current settings and reset the wireless access point to the original factory default
settings:
1. In Step 1 of the previous section, select Restore Defaults from the side menu (see Figure 4-
5).
2. Select the Yes radio button next to the Restore to factory default settings option.
3. Click Apply.
Figure 4-5 Reboot the AP
Warning: Do not try to go online, turn off the Access Point, shut down the
computer or do anything else to the Access Point until it finishes
rebooting. When the power light turns green, wait a few more
seconds before doing anything with the Access Point.

NETGEAR WN802T Specifications

General

Maximum data transfer rate	300 Mbit/s
MAC address filtering	Yes
Minimum system requirements	-Internet Explorer 6.0; -4 GHz 802.11n / 2.4 GHz 802.11 b/ g;
Compatible operating systems	Microsoft Windows 98, Me, 2000, XP, Mac OS, UNIX, / Linux

Weight and Dimensions

Weight	560 g
Dimensions (WxDxH)	225.5 x 172 x 39 mm
