7.7 SPARE PARTS
QTY PART No. DESCRIPTION
STANDARD ITEMS
2 4211 V BELT A890 (A34)
2 5145 TIMING BELT 150-L-050
2 6015 TIMING BELT 225-L-050
2 6018 TIMING BELT 285-L-050
2 6209 BEARING SELF LUBE 25MM
2 6212 BEARING SELF LUBE 20MM
2 6213 BEARING SELF LUBE 16MM
2 6282 TIMING BELT 110-XL-037
2 6650 TIMING BELT 210-L-050
3 706 CONNECTING LINK
2 9854 TIMING BELT 270-L-050
2 10243 ASSEMBLY SERRATED ROLLER
1 10276 SLAT BELT 1FT
5 14978 FILTER PAD 120 X 120
3 20447 RUBBER 3 X 155 X 355 BLACK
1 23127 CLUTCH BRAKE
1 23420 PANEL FAN 24V DC
6 23432 3AMP QUICK BLOW FUSE
2 26134 OPTO RELAY
1 26182 CONTACTOR
3 27096 6 AMP FUSE
3 27097 10 AMP FUSE
1 28285 GUARD SWITCH
1 28422 SENSOR TEN-5-P (PRODUCT AND REJECT)
1 28427 5 METRE SENSOR CABLE
1 28459 CHANGEOVER RELAY
1 28478 1KΩ 10 TURN POT
1 28818 FOCUSING LENS AF-3
1 28897 MICROSWITCH
1 29224 FIBRE OPTIC LEAD
OPTIONAL ITEMS
1 16667 LABEL SENSOR – BALL CONTACT - OMRON
1 28420 LABEL SENSOR – OPTICAL - DATASENSOR
1 29876 LABEL SENSOR – ULTRASONIC - LEUZE
1 29253 OVERPRINT DETECTOR - DATASENSOR
1 29253 MISSING LABEL LUMINESCENCE - DATASENSOR
