NDiS M535 User Manual
Chapter 4: BIOS Setup
Hardware Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Advanced
Version 2.17.1255. Copyright (C) 2016 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
FAN Mode Setting
Hardware Monitor
FAN Mode
FAN Level
System FAN Mode
CPU Temperature(DTS)
System Temperature
VCORE
VCC5
VCC3
FAN Speed
[Smart FAN]
[Disabled ( 0%)]
[System FAN Disabled]
: +41 °c
: +35 °c
: +1.008 V
: +5.083 V
: +3.304 V
: 2264 RPM
FAN Mode
Configures the fan mode. The options are Disabled ( 0%), Smart Fan,
Programmable Fan and FAN Full On.
System FAN Speed
Enables or disables fan speed control of the system.
CPU Temperature(DTS)
Detects and displays the current CPU temperature.
System Temperature
Detects and displays the internal temperature of the system.
VCORE to VCC3
Detects and displays the output voltages.
FAN Speed
Detects and displays the current fan speed.
