Chapter 1: Product Introduction
NEX 605 User Manual
Knowing Your NEX 605
SIM Card Connector
Audio Connectors
LAN2/ USB LAN1/ USB
LAN1/ USB
eSATA
USB 8/9
HDMI
LVDS Backlight
Panel Power Select
COM & VGA
PS/2 KB/ MS
PS/2 KB/ MS
COM2
LVDS Backlight Panel
COM3
COM4
LVDS
IR Connector
Intel
®
ICH10R
FAN Connector
FAN Connector
USB6/7 DIMM1 DIMM2
Line-in
SATA1
PCIe x4
SATA2
SATA3
CMOS
SATA4
SM BUS
SATA5
RTC Battery
FP Control
ATX/AT Select
Mini-PCIe
SATA & LAN LED
ATX Power Connector
