Chapter 1: Product Introduction
NEX 605 User Manual
Hardware Specications
CPU Support
• Intel
®
Atom™ processor D2550 1.86GHz CPU
Main Memory
• Dual 204-pin SO-DIMM socket supports up to 4 GB DDR3 800/1066
MHz SDRAM
Chipset
• Intel
®
ICH10R support Intel
®
Matrix Storage technology of RAID 0/ 1/ 5/
10 configuration
BIOS
• AMI BIOS
• Plug & Play support
• Advanced Power Management
• Advanced Configuration & Power Interface
• 8M bits SPI ROM
On-board LAN
• 2x Intel 82574L PCI Express Gigabit Ethernet
• Support Boot From LAN (PXE)
• 2x RJ45 with LEDs build-in 2x dual stackable USB type A connectors on
edge I/O
Display
• Intel
®
Atom™ processor D2550 integrated 3D graphics engine, which
enhances Gfx & Video, support DX10.1, OpenGL 3.0, Full HD-Decode
(MPEG2,VC1,AVC,H.264), delivers sophisticated graphics for large
display applications, supports dual independent at graphics base
frequency up to 640MHz, and provides a wealth of options for high-
resolution displays.
• Analog VGA interface
• Resolution up to 1920x1200 75Hz
• HDMI interface
• 1x HDMI Interface
• Resolution up to 1920x1200
• LVDS interface
• Single (24bit) LVDS panel, resolution up to 1440 x 900 DF13 20-pin LVDS
connector for internal connection
• CCFL interface
• 1x CCFL for LCD Panel Backlight Inverter
Audio
• Realtek ALC886 CODEC for High Definition
• 1x Mic-in/ 1x speaker-out by audio jack on edge I/O and 1x line-in by pin
header.
Expansion
• 1x Mini-PCIe (1x full-size/ SIM tray)
• 1x PCIE X4 slot
