Chapter 2: Jumpers and Connectors
NEX 605 User Manual
LVDS Backlight Power Select
Connector type: 1x3 3-pin header
Connector location: JP7
Pin Settings
1-2 3.3V
2-3 5V
1-2 On: default
Pin Definition
1 VCC3
2 VCC_SEL
3 VCC5
