Nexcom NEX 605 - Board Dimensions

Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved
28
Chapter 2: Jumpers and Connectors
NEX 605 User Manual
Board Dimensions
0.00
33.02 81.86
165.09 170.00
6.35
163.82
104.6953.70
0.00
9.83
37.83
63.33
83.29
107.06
129.39
147.86
163.83
170.00
