Chapter 2: Jumpers and Connectors
NEX 605 User Manual
SMBus Connector
Connector type: 1x4 4-pin header
Connector location: JP2
Line-in Connector
Connector type: 1x4 4-pin header
Connector location: J8
Pin Definition
1 LINEIN_R
2 LINEIN_JD
3 GND
4 LINEIN_L
Pin Definition
1 3VSB
2 SMB_DATA
3 SMB_CLK
4 GND
