Next Matrix Live - Use of MASTER CHASE Fader

The Grand Master fader (Fig. 29) allows to adjust the bright gene-
ral intensity of all the units
, (only if the connected units have
the dimmer channel).
Keep the fader always to the maximum 100%, keep to 0 value
only to create a blackout.
MATRIX LIVE IS ENDOWED WITH A GENERAL CONTROL LEVEL OUT-
PUT, OF ALL "DIMMER" CHANNELS OF THE INTELLIGENT UNITS.
6.10 USE OF GRAND MASTER FADER
GB
GRAND
MASTER
The Master Chase fader (Fig. 30) allows to adjust the bright gene-
ral intensity of the
chase and relative step.
For have the bright intensity of chase/step at 100% keep the
fader to the maximum, keep to 0 value only to create a
blackout.
MATRIX LIVE IS ENDOWED WITH A GENERAL CONTROL LEVEL OUT-
PUT, OF DIMMER CLASSIC CHANNELS.
6.11 USE OF MASTER CHASE FADER
MASTER
CHASE
Fig. 27
Fig. 28
