Main components
Compressor (CM)
Compressor (CM)
screws
screws
NOTE
Before the com-
pressor is removed,
F2040 must be
drained of refriger-
ant.
1 Remove the top panel and
front hatch.
2 Slacken off 6 screws for the
side panel.
3 Remove the side panel.
Screw
4 Slacken off the 5 screws
holding the service valves'
mounting plate to the heat
pump.
77Chapter 7 | Component replacementNIBE™ F2040
