Compressor (CM)
Tho-D
7 Cut off the two cable ties
and pull out the sensor (Tho-
D).
CNEEV2
CNEEV1
Screw
(Earth)
Strap CNB CNTH CNPSCNTP
8 Disconnect the contacts as
illustrated (PWB1).
9 Unscrew the ground cable.
10 Disconnect the blue-
white connector on the ter-
minal board.
Contact
79Chapter 7 | Component replacementNIBE™ F2040
