Control
FIGHTER 1120
44
Hot water temperature
Menu 1.12 Return
Pressing the enter button returns you to menu 1.0
Return
1.12
Menu 1.11.4 Return
Pressing the enter button returns you to menu 1.11.0
Return
1.11.4
Menu 1.11.2 Diff. Pool
The difference from the value in menu 1.11.1 when
pool heating starts is stated here.
The value is adjustable between 0.5 and 9.5°C.
1.5°C
Diff. Pool
1.11.2
Menu 1.11.3 Pool Time
The maximum time that pool heating can run is stated
here. The value is adjustable between 5 and 60 min-
utes.
20 min
Pool Time
1.11.3
U
U
Menu 2.4 Flow Temp./MAX
The set maximum level for the supply temperature to
the heating system is shown here. The value is
adjustable between 10 and 80 °C
The calculated flow temperature never exceeds the
set level irrespective of the outdoor temperature,
curve slope or heating curve offset.
Menu 2.1 Curve coefficient
The selected curve slope (heating curve) is shown
here. The “Own curve” function is activated at value 0,
see menu 2.6.0. The value can be set between curve
0 and 15.
Menu 2.2 Heating curve offset
The selected heating curve offset is shown here. The
value is adjustable between -10 and +10.
Menu 2.3 Flow Temp./MIN
The set minimum level for the supply temperature to
the heating system is shown here. The value is
adjustable between 10 and 80 °C.
The calculated flow temperature never drops below
the set level irrespective of the outdoor temperature,
curve slope or heating curve offset.
35.5 (55)°C
Flow Temp./MAX
2.4
9
Curve coefficient
2.1
-1
Heating curve offset
2.2
35.5 (15)°C
Flow Temp./MIN
2.3
U
U
N
N
Flow temperature
Menu 1.11.1 Pooltemp./Setting
The temperature when pool heating is stopped is stat-
ed here.
The value is adjustable between 15 and 55 °C.
19.0 (20)°C
Pooltemp./Setting
1.11.1
U
