Control
FIGHTER 1120
46
Flow temperature system 2
Menu 3.4 Flow temp2./MAX
The set maximum level for the supply temperature to
the heating system is shown here. The value is
adjustable between 10 and 80 °C.
The calculated flow temperature never exceeds
the set level irrespective of the outdoor temperature,
curve slope or heating curve offset.
Menu 3.1 Curve coefficient 2
The selected curve slope (heating curve) is shown
here. The “Own curve” function is activated at value 0,
see menu 3.6.0. The value can be set between curve
0 and 15.
Menu 3.2 Offs.heating curve 2
The selected heating curve offset is shown here. The
value is adjustable between -10 and +10. NOTE! The
value is changed using the “Heating curve offset”
knob.
Menu 3.3 Flow temp2./MIN
The set minimum level for the supply temperature to
the heating system is shown here. The value is
adjustable between 10 and 80 °C.
The calculated flow temperature never drops below
the set level irrespective of the outdoor temperature,
curve slope or heating curve offset.
35.5 (45)°C
Flow temp2./MAX
3.4
9
Curve coefficient 2
3.1
-1
Offs.heating curve 2
3.2
35.5 (15)°C
Flow temp2./MIN
3.3
U
U
N
N
Flow temperature
Menu 2.10 Return
Pressing the enter button returns you to menu 2.0.
Return
2.10
Menu 2.9.1 Cooling curve
The selected cooling curve (curve slope) is shown
here. The value can be set between curve 1 and 3.
2
Cooling curve
2.9.1
U
Menu 2.9.5 Return
Pressing the enter button returns you to menu 2.9.0
Return
2.9.5
Menu 2.9.2 Offset cold curve
The selected cooling curve offset is shown here. The
value is adjustable between -10 and +10.
0
Offset cold curve
2.9.2
U
Menu 2.9.3 Start temp. cooling
The outdoor temperature when cooling is activated is
shown here. The value is adjustable between -20 and
35 °C.
25
Starttemp. cooling
2.9.3
U
Menu 2.9.4 Diff Passive/Active
If the flow temperature exceeds the calculated flow
temperature + this value the system switches to active
cooling. The value can be set between curve 1 and 9.
4
Diff Passive/Active
2.9.4
U
