Control
49
FIGHTER 1120
Brine in/out temperature
Menu 5.13 Bulb temperature
The suction gas temperature is shown in this menu.
5.0°C
Bulb temperature
5.13
U
Menu 5.15 Compressor type
No function.
Normal
Compressor type
5.15
U
Menu 5.22 Return
Pressing the enter button returns you to menu 5.0.
Return
5.22
Menu 6.3 Return
Pressing the enter button returns you to menu 6.0.
Return
6.3
Menu 6.1 Room compensation
A factor is selected here that determines how much
the flow temperature is affected by the difference
between the room temperature and the set room tem-
perature. A higher value gives a greater change. The
value is adjustable between 0.2 and 3.0.
1,0
Room compensation
6.1
Menu 6.2 Heating system
You select here whether the room sensor should acti-
vate system 1 (menu 2.0) or system 2 (menu 3.0).
Shunt 1
Heating system
6.2
Menu 7.1 Date
The current date is set.
Menu 7.3.0 Temp set back time 1
Settings, e.g. for night reduction can be selected in the
sub-menus to this menu.
2003-09-24
Date
7.1
Temp set back time 1
7.3.0
Menu 7.3.1 Heating sys per. 1
The shunt system to be affected by day change period
1 is selected here. When shunt group 2 is installed
both Shunt 1 and 2 can be selected.
Off
Heating sys per. 1
7.3.1
Menu 7.3.2 Set back temp. +/-
Changes to the room temperature with a day change,
e.g. the night reduction is set here. The value is
adjustable between -10 and 10.
0
Set back temp. +/-
7.3.2
Menu 7.2 Time
Here the current time is set.
13:39
Time
7.2
Clock
Room temp./Settings
U
U
Menu 7.3.3 - 7.3.9 Set Time Monday - Sunday
The time for the day change, e.g. night reduction is
chosen here.
Set Time Monday
7.3.3
U
N
N
U
Menu 5.14 Condensor out temp.
The heat medium temperature after the condensor is
shown here.
Condensor out temp.
5.14
U
U
U
