Nice Filo

English – 2
English
The devices of this kit and other optional accessories belong to the Nice Home automation system and are designed to automate a sliding gate for
residential use.
-
sidered improper and is forbidden
The kit comprises an electromechanical gearmotor with 24 V direct current
for manually moving the gate in case of a power outage
the automation.
Connection of the control unit to the various devices occurs through the ECSBus system (a single cable with 2 wires).
which ensures that the automation can execute a certain
number of manoeuvres during the hours following a power outage .
2
PRODUCT DESCRIPTION AND INTENDED USE
3
INSTALLATION
Certain devices and accessories mentioned in this manual are optional and not included in the kit.
The end stops are not included in the kit and do not belong to the Nice Home range of products.
Consult the Nice Home product catalogue or visit the website www.niceforyou.com
3.1 - VERIFYING THE SUITABILITY OF THE GATE AND ENVIRONMENT
the gate’s label.
installation of the gate or poor maintenance of the latter.
• Manually move the gate leaf in both directions (open/closed) and make sure that the movement takes place with constant friction at every point along
• Manually bring the door of the gate into any position then leave it closed and make sure that it does not move.
• Check that there is no risk of derailment or that the gates may come o their guides.
ground.
• Check that the installation surfaces of the various devices are solid for guaranteeing a stable anchorage and that they are protected and guarded
3.2 - VERIFYING THE PRODUCT’S APPLICATION LIMITS
01. Check the overall dimensions of the gearmotor ( Fig. 2
the foundation excavation for the passage of the cable trays.
02. Check that the estimated durability is compatible with the intended use (Paragraph 2.5).
03. Ensure that all limitations, conditions and warnings appearing in this manual can be fully observed.
3.3 - PRODUCT TECHNICAL SPECIFICATIONS
Model type FILO400C - FILO400CST/AU01 -
FILO400CSP/AU01
FILO600C - FILO600CST/AU01 -
FILO600CSP/AU01
Product type Electromechanical gearmotor for automatic gate and door automations with incorporated con -
trol unit, inclusive of radio receiver for ECCO5 transmitters (various models)
Technology adopted A 24 V motor
inside the motor, but separate from the control unit, ( not present in FILO400CSP/AU01 and
FILO600CSP/AU01) reduces the mains voltage to the nominal 24 V voltage used throughout
the automation system.
Peak thrust 10 Nm 13 Nm
Nominal torque 3.5 Nm 5.2 Nm
Speed (no load) 0.30 m/s 0.20 m/s
Nominal torque speed 0.20 m/s 0.15 m/s
Maximum frequency of cycles 24 cycles/hour at 55°C (40 cycles/hour at
25°C)
11 cycles/hour at 55°C (20 cycles/hour at
25°C)
Maximum continuous cycle time 30 minutes 15 minutes
Application limits Its structural characteristics make it suitable
for use on gates weighing up to 400 kg and
up to 5.5 m long.
Its structural characteristics make it suitable
for use on gates weighing up to 600 kg and
up to 7 m long.
Mains power supply 230 V
(+10% –15%) 50/60Hz (FILO400CST/AU01 / FILO600CST/AU01 250 V~ 50/60 Hz) -
FILO400CSP/AU01 / FILO600CSP/AU01 24 V
Maximum power input 370 W 420 W
Emergency power supply
Flashing light output
Step A Step B
