9.4 - DELETING THE MEMORY OF THE INDIVIDUAL TRANSMITTER FROM THE CONTROL UNIT’S MEMORY
the transmitter to be cancelled and simultaneously be able to access the control unit (before proceeding, open the gearmotor – Fig. 9).
• Procedure with transmitter memorised in Mode 1
01. On the control unit (Fig. 29) press and hold button P4 until the end of the procedure .
02. When led L4 lights up, while keeping button P4 pressed , press and hold also any button of the transmitter to be cancelled, until led L4 ashes
then release both buttons .
Repeat the procedure for each transmitter to be cancelled.
• Procedure with transmitter memorised in Mode 2
01. On the control unit (Fig. 29) press and hold button P4 until the end of the procedure .
02. When led L4 lights up, while keeping button P4 pressed , press and hold also the button of the transmitter to be cancelled, until led L4 ashes
then release both buttons
Repeat the procedure for each transmitter to be cancelled.
9.5 - COMPLETE DELETION OF THE RADIO MEMORY
the control unit (before proceeding, open the cover of the gearmotor – Fig. 9).
01. On the control unit (Fig. 29) press and hold button P4 .
02. Check that led L4 lights up for 4/5 seconds, that it switches o then ashes 3 times.
03. Precisely at the 3
rd
ash release button P4 .
04. Check that led L4 emits very fast ashes.
05. Check that led L4 emits 5 slow ashes = deletion completed.
9.6 - INSTALLING THE BACK-UP BATTERY (model PR100)
must be made exclusively after completing all the
installation and programming stages
To install the back-up battery and connect it to the control unit, see Fig. 30 and consult the respective instruction manual.
When the automation is powered by the back-up battery, 60 seconds after a manoeuvre is completed the control unit automatically switches o the
consumption (very important when the automation is powered by a battery )
9.7 - INSTALLING THE SOLAR POWER SYSTEM KIT model SOLEKIT
C IT MUST NOT BE POWERED
by the electricity grid at the same time .
Fig. 31 and consult the relevant instruction manual.
