Nice Filo

English – 16
English
L2 led Status Action
O *
On
The device recognition phase has
not been carried out, or there are
errors in the memorised data
Perform the position recognition phase again (see Par. 5.4)
Device recognition phase under way Indicates that the search phase for connected devices is under way (it lasts a few
seconds at the most)
L3 led Status Action
O * Cycle operation
On
Complete-cycle operation
* or it could be in “Standby” mode
9.11 - SPECIFICATIONS
9.11.1 - ECSBus system
ECSBus is a system that allows for connecting ECSBus devices using just two wires, which convey both electricity and communicat ion signals. All
address assigned to each device during installation.
Photocells and other devices adopting this system can be connected to the ECSBus, such as safety devices, control buttons, indicator lights etc. For
information on ECSBus devices, consult the Nice Home range product catalogue or visit the website www.niceforyou.com
Through a recognition procedure the control unit recognises one-by-one all the devices connected and this enables it to detect with extreme precision
all possible anomalies during the automation’s normal operation. For this reason, whenever a device connected to the ECSBus is added or removed,
it is necessary to repeat the recognition procedure for these additional devices (Par. 9.2.1).
9.11.2 - Stop input
with normally closed (NC) contacts can be connected to this input, as well as devices with 8.2 k constant resistance (e.g. sensitive edges). With sui -
table arrangements, multiple devices – even of dierent type – (read Table 10) can be connected to the Stop input.
TABLE 10
Note 1
Note 2
Note 3 any
limit.
Note 4
2
nd
1
st
NO NC 8.2 k
NO In parallel (Note 2 ) (Note 1 ) In parallel
NC (Note 1 ) In series ( Note 3 ) In series
8.2 k
In parallel In series (Note 4 )
guarantee Category 3 safety against faults.
Similarly to the ECSBus, the control unit recognises the type of device connected to the Stop input when the recognition proced ure is carried out.
9.11.3 - Product durability
other words, the sum of all factors that contribute to product wear (Table 11
01. Add up all the values of the entries in Table 11
02. In Graph 1
TABLE 11
FILO400C FILO600C
Severity index
Length of the leaf
< 3 m
3 - 4 m
4 - 5 m
5 - 6 m
6 - 7 m
0%
10%
20%
25%
-
0%
5%
10%
15%
20%
Weight of the leaf
< 200 kg
200 - 300 kg
300 - 400 kg
400 - 600 kg
10%
20%
30%
-
0%
10%
20%
30%
20% 20%
15% 15%
Motor force level 4 setting 15% 15%
Note – The data refers to a sliding gate which is properly balanced and in good wor -
king order
GRAPH 1
50.000
100.000
150.000
200.000
250.000
300.000
Severity index (%)
manoeuvre cycles
the basis of design calculations and the results of tests performed on prototypes. Being only an estimate, it does not constitute any form of guarantee
on the actual lifespan of the product.
