ENGLISH – 19
7.2 LEVEL 1 PROGRAMMING (ON-OFF)
All the Level 1 functions are factory-set to “OFF” with the exception of parameter L5” and can be modied at any time. To check
the various functions, refer to “Table 5”. Take care during modication procedures, as there is a maximum time interval of 10 sec-
onds between pressing of different buttons; otherwise the procedure terminates automatically and stores the changes made up to
that time.
7.2.1 Level 1 programming procedure
m
The user has maximum 10 seconds to press the buttons consecutively during the programming procedure,
after which time the procedure terminates automatically and memorises the changes made up to then.
To perform Level 1 programming:
1. press and hold the
o
button until LED “L1” starts ashing
2. release the
o
button when LED “L1” starts ashing
3. press the
p
or
q
button to move the ashing LED to the LED associated with the function to be modied
4. press the
o
button to change the status of the function:
short ash = OFF
long ash = ON
5. wait 10 seconds (maximum time) to exit the programming mode.
l
To set other functions to “ON” or “OFF”, while the procedure is running, repeat points 2 and 3 during the phase
itself.
Table 5
LEVEL 1 FUNCTIONS (ON-OFF)
LED Function Description
L1 Automatic closing
Function ENABLED: after an opening manoeuvre there is a pause (equal to the set pause time), after
which the control unit automatically starts a closing manoeuvre. The pause time is set by default to 30
seconds.
Function NOT ENABLED: the system works in “semi-automatic” mode.
L2 Close after photo
Function ENABLED: the behaviour changes depending on whether the “Automatic Closing” function is
enabled or not.
When “Automatic Closing” is disabled: the boom gate always reaches the fully open position (even if the
Photo disengages rst). When Photo disengages, automatic closing is triggered with a 5-second pause.
When “Automatic Closing” is enabled: the opening manoeuvre stops immediately after the photocells have
disengaged. After 5 seconds, the gate will start closing automatically.
The “Close After Photo” function is always disabled in manoeuvres interrupted by a Stop command.
Function DISABLED: the pause time is that which has been programmed or automatic re-closing will not
take place if the function is disabled.
L3 Always Close
Function ENABLED: in the event of a blackout, even of short duration, if the control unit detects that the
gate is open once the electricity is restored, it automatically starts a closing manoeuvre, preceded by a
3-second pre-ashing sequence.
Function DISABLED: when the electricity is restored, the gate remains in the same position.
L4 Stand-by
Function ENABLED: 1 minute after the completion of the manoeuvre, the control unit switches off the
BlueBUS output (and, therefore, the devices) and all LEDs, with the exception of the BlueBUS LED, which
ashes more slowly. When the control unit receives a command, it restores full operation.
Function DISABLED: there will be no reduction in consumption.
This function is useful, in particular, during operation with the back-up battery.
L5 Long slowdown
Function ENABLED: allows for doubling the space from which the slowdown starts, during both the
opening and closing manoeuvres.
Function DISABLED: short slowdown.
L6 Pre-ashing
Function ENABLED: a 3-second pause can be added between the switching on of the warning light and
the start of the manoeuvre, to warn the user in advance of a potentially dangerous situation.
Function DISABLED: the signalling of the warning light coincides with the start of the manoeuvre.
L7 Sensitivity
Function ENABLED: allows for considerably increasing the motor’s sensitivity in detecting obstacles. If
used to aid impact force detection, the “Speed” and “Motor force” parameters in the Level 2 menu must
also be adjusted.
L8
Motor rotation
direction
Function ENABLED: allows for inverting the motor’s rotation direction in order to install the barrier to the
right.
Function DISABLED: the factory setting, with the barrier closing towards the left.
WARNING: when this function is enabled, the “Opening” and “Closing” positions must be learned (see the
Learning of the mechanical stop positions” paragraph).
l
During normal operation, LEDs “L1 ... L8” are on/off depending on the status of the respective function; for
example, “L1” is lit when the “Automatic Closing” function is enabled.
l
During the manoeuvre, LEDs “L1 ... L8” ash to signal the force required to move the boom at that time. If “L1”
ashes, the force required is low and so forth, until LED “L8” ashes to signal the maximum force.
