Please note that there is no relation between the force level indicated by the LEDs during the movement (which
is an absolute value) and the level indicated by the LEDs during the force (which is a relative value) program-
ming phase. See LEDs “L5” and “L6” in “Table 6”.
7.3 LEVEL 2 PROGRAMMING (ADJUSTABLE PARAMETERS)
All the Level 2 parameters are factory-set as highlighted in “GREY” in “Table 6” and can be modied at any time. The parameters
can be set to a scale of 1 to 8. The check the value corresponding to each LED, refer to “Table 6”.
7.3.1 Level 2 programming procedure
m
The user has maximum 10 seconds to press the buttons consecutively during the programming procedure,
after which time the procedure terminates automatically and memorises the changes made up to then.
To perform Level 2 programming:
1. press and hold the
o
button until LED “L1” starts ashing
2. release the
o
button when LED “L1” starts ashing
3. press the
p
or
q
button to move the ashing LED to the “entry LED” associated with the parameter to be modied
4. press and hold the
o
button. With the
o
button pressed:
– wait roughly 3 seconds, until the LED representing the current level of the parameter to be modied lights up
– press the
p
or
q
button to shift the LED associated with the parameter’s value
5. release the
o
button
6. wait 10 seconds (maximum time) to exit the programming mode.
l
To set multiple parameters during the procedure's execution, repeat the operations from point 2 to point 4 dur-
ing the phase itself.
Table 6
LEVEL 2 FUNCTIONS (ADJUSTABLE PARAMETERS)
Entry LED Parameter LED (level) Set value Description
L1* Pause Time
L1 5 seconds
Adjusts the pause time, in other words,
the time before automatic re-closure.
It is only effective if the “Automatic
Closing” function is enabled.
L2 10 seconds
L3 20 seconds
L4 40 seconds
L5 60 seconds
L6 80 seconds
L7 120 seconds
L8 200 seconds
L2**
Step-by-Step
function
L1 Open - Stop - Close - Stop
Controls the sequence of controls
associated with the Sbs input or the 1st
radio command.
L2 Open - Stop - Close - Open
L3 Open - Close - Open - Close
L4 Condominium (more than 2 sec triggers “Stop”)
L5
Condominium 2 (less than 2 sec triggers
“Partial Open”)
L6 Step-by-Step 2
L7 Hold-to-run
L8
Opening in “semi-automatic” mode, closing in
“hold-to-run” mode
L3* Motor speed
L1 Speed 1 (30% - slow)
Adjusts the motor speed during normal
manoeuvres.
L2 Speed 2 (47%)
L3 Speed 3 (65%)
L4 Speed 4 (82%)
L5 Speed 5 (100% - fast)
L6 Open V3, close V2
L7 Open V4, close V3
L8 Open V5, close V4
L4** FLASH output
L1 Gate open indicator
Selects the device connected to the
FLASH output.
L2 Enabled if boom is closed
L3 Enabled if boom is open
L4 Warning light
L5 Boom light warning light
L6 Electric lock
L7 Suction cup
L8 Maintenance indicator
